Multi Head Weigher High Speed Pouch Packing Machine

High Speed Packing Machine Manufacturers

Technical Specification

Packing Range 10 gm to 1kg
Filling System (Multi Head Weigher) 10 Head weigh Filler / 14 Head weigh Filler
Filling Accuracy 0.5%
Type of Sealing Center Seal
Packing Material Kurkure, Puffs, Potato Chips, Namkeen, Grains Ets.
Film Size 100mm - 550mm width 100mm - 200mm length
Film Roll Type Laminated Filmin Roll Supported Film E.g. Aluminum Foil Pe, PP
Speed 55 to 60 bag/min, 85 to 90 bag/min (Varies with the nature of product & filling range)
Power 3kw 230v / AC / Single Phase / 50hz
Machine Size 72" x 96" x 126
Weight 1400kg (Approx)
Compressed Air 6CFM @ 6bar
Optional Batch Coding Device

We are Fastest Growing Company in Packaging Machinery & Food Project Consultancy.
